SK302L Micro S Shaped Force Sensor

Model: SK302L
Category: S type Load Cell
Capacity: 200,500g
Rated Output: 1.0/2.0±10%mV/V
Product Orgin: China
The load cell can be customised for capacity, accuracy, dimension and other parameters.

SK302L Micro S Shaped Force Sensor uses metal foil strain gauge technology to provide a mV/V output with a maximum non-linearity of 0.05% and is available in a choice of 200g / 500g capacities. M3 threaded holes on both sides of the measuring element can be used for mounting accessories such as load buttons, eye bolts, hooks, etc., in order to satisfy the requirements of the different applications in the force detection and automatic processing sections.

Specifications Technique
Capacity 200,500g
Rated output 1.0/2.0±10%mV/V
Zero balance ± 0.05mV/V
Creep30min 0.05%F.S.
Non-linearity 0.05%F.S.
Hysteresis 0.05%F.S.
Repeatability 0.05%F.S.
Temp.effect on output 0.05%F.S./10
Temp.effect on zero 0.05%F.S./10
Input impedance 400/350±5Ω
Output impedance 400/350±5Ω
Insulation 5000MΩ/100VDC
Recommended excitation 5~15V
Maximum excitation 20V
Compensated temp range -10~60
Operation temp range -20~80
Safe overload 150%F.S.
Ultimate overload 200%F.S.
Cable size Φ2×3000mm
Material: Aluminium alloy/Stainless steel
Weight: 0.1kg
